Advantage

01 The highest thermal deformation temperature is 210 degrees Celsius;
02 Excellent long -term hydrolysis stability;
03 Passed FDA, and other certifications;
04 Repeated high temperature and high pressure steam sterilization;
05 Excellent toughness and impact strength;
06 Light weight, 50%of traditional materials such as aluminum.

PSU board stick color and color code

PPSU board stick color and color code

Color numberBL001N000BB09DB0099GR350Y159GG6126R8040W002

PEEK, PPSU, PSU typical Performance Table

Polymer performance/typeUnitPEEK5600GPEEK5600GF30PEEK5600CF30PPSUPSUTest standard
Fiber contentNot fill30%glass fiber30%carbon fiberNot fillNot fill————
Tensile StrengthMPa1011632207269ISO 527-1/-2
Tensile modulusGPa3.511212.22.5ISO 527-1/-2
Elongation at break%10-202.81.760-12050-100ISO 527-1/-2
Bending strengthMPa15726032191103ISO 178
Flexural modulusGPa3.510.517.92.42.6ISO 178
Notched impact strengthJ/mNo Break860637No BreakNo BreakISO 180/IU
Heat distortion temperature
1.82MPa		℃160315315210174ISO 75-1/-2
Linear thermal expansion
coefficient flow direction		ppm/℃472075756ISO11359-1/-2
Linear coefficient of thermal
expansion in the transverse direction		ppm/℃5067565756ISO11359-1/-2
Water absorption rate24h%0.10.10.10.40.3ISO 62
Densityg/cm³1.31.531.411.291.24ISO 1183

ps:This data is the average value of the material and cannot be used as the acceptance standard. The average value of linear thermal expansion is between 0-150 ° C.
